Description
The 2.5 Inch Lift Kit | FOX Coil-Over | Chevy Trail Boss or GMC AT4 1500 (25-26) 4WD | Diesel | FOX 2.5 Performance Elite Coil-Over / FOX 2.5 Performance Elite Series Shock is a complete suspension upgrade that raises your Chevy Trail Boss or GMC AT4 1500 (2025-2026) 4WD and makes room for larger rubber. It raises the front 2.5 in. and the rear 1 in. Once installed, it makes room for tires up to 33 x 12.5 in.
This configuration pairs FOX 2.5 Performance Elite Coil-Over front coil-overs with FOX 2.5 Performance Elite Series Shock rear shocks.
Features
- Lift height: 2.5 in. front, 1 in. rear (block)
- Heavy 1/4 in. laser-cut steel crossmembers that keep the underside clear
- Front skid plate adds underbody protection and stiffens the front subframe
- CNC-machined ductile iron knuckles restore proper steering geometry at the taller height
- Front differential relocation brackets to protect CV joint angles
- Includes FOX 2.5 Performance Elite Coil-Over
- Clearance for tires up to 33 x 12.5 in.
Specifications
- Life Cycle Status Code
- 2
- Coil Over Option
- FOX 2.5 Performance Elite Coil-Over
- Drivetrain
- 4WD
- Engine Type
- Diesel
- Front Lift Height
- 2.5 in.
- Max Tire Size
- 33 x 12.5 in.
- Rear Lift Height
- 1 in.
- Rear Lift Method
- Block
- Rear Shock Option
- FOX 2.5 Performance Elite Series Shock
- Shocks Included
- Yes
