Description

The 2.5 Inch Lift Kit | FOX Coil-Over | Chevy Trail Boss or GMC AT4 1500 (19-24) 4WD | Diesel | FOX 2.5 Performance Elite Coil-Over / FOX 2.5 Performance Elite Series Shock is a complete suspension upgrade that raises your Chevy Trail Boss or GMC AT4 1500 (2019-2024) 4WD and makes room for larger rubber. It provides 2.5 in. of front lift. Once installed, it makes room for tires up to 35 x 12.5 in.

This configuration pairs FOX 2.5 Performance Elite Coil-Over front coil-overs with FOX 2.5 Performance Elite Series Shock rear shocks.

Features

  • Lift height: 2.5 in. front
  • Tall-arch 1/4 in. steel crossmembers built for clearance and strength
  • Bolt-together skid plate system shields key components off-road
  • CNC-machined ductile iron knuckles restore proper steering geometry at the taller height
  • Front differential relocation brackets to protect CV joint angles
  • Includes FOX 2.5 Performance Elite Coil-Over
  • Clearance for tires up to 35 x 12.5 in.

Specifications

Life Cycle Status Code
2
Coil Over Option
FOX 2.5 Performance Elite Coil-Over
Drivetrain
4WD
Engine Type
Diesel
Front Lift Height
2.5 in.
Max Tire Size
35 x 12.5 in.
Rear Lift Method
Block
Rear Shock Option
FOX 2.5 Performance Elite Series Shock
Shocks Included
Yes
California Prop 65 Notice
WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
Drive
4WD
Fuel Type
Diesel
Kit Components
Includes one BDS011316, 2019-2024 Chevy/GMC 1500 4 inch Rear Box Kit, UPC Code 658848611737Includes one BDS021664, 2019-2024 Chevy/GMC 1500 Knuckle Box 1of2 w/UCA (4 inch and 6 inch Compatible), UPC Code 658848615056Includes one BDS021665, 2019-2024
Last Update
2026-10-20 15:39:21
Lift Height
2.5 Inch
Sold As
Kit
Universal
No
Vehicle Type
Truck/SUV
Warranty
Lifetime Replacement Warranty Extends to Cover all BDS Hard Parts
2.5 Inch Lift Kit | FOX Coil-Over | Chevy Trail Boss or GMC AT4 1500 (19-24) 4WD | Diesel | FOX 2.5 Performance Elite Coil-Over / FOX 2.5 Performance Elite Series Shock

2.5 Inch Lift Kit | FOX Coil-Over | Chevy Trail Boss or GMC AT4 1500 (19-24) 4WD | Diesel | FOX 2.5 Performance Elite Coil-Over / FOX 2.5 Performance Elite Series Shock

BDSBDS788FPE
