Series 20XL Hydraulic Winch
The Series 20XL Hydraulic Winch is built for the toughest industrial applications, featuring a standard drum, manual clutch, and a 20,000-pound pull capacity. It’s ideal for trailers, roll-back carriers, and other severe-duty applications.
Please Note: This product requires a compatible bumper or mounting plate for proper installation. Visit our Mounting & Protection category for available options.
Warn Industrial hydraulic winches offer top-tier performance for all hydraulic winching applications. With powerful hydraulic motors, these winches ensure extended duty cycles and outstanding performance. The two-stage planetary gear train, made of hardened steel, guarantees efficient operation with fast line speeds, providing reliability and performance in even the harshest conditions. Like their electric counterparts, these winches meet global quality and safety standards.
Key Features:
- 8.0 Cubic Inch High-Performance Motor: 20,000-pound capacity, great for severe-duty applications like trailers and roll-back carriers.
- Spring Applied Disc Brake: Designed to hold the full-rated load.
- Hardened Aircraft Grade Nickel Chromalloy Two-Stage Planetary Gear Train: Ensures maximum speed and reliability.
- Meets SAE J706 and CE Specifications: Complies with industry standards for safety and durability.
- Limited Lifetime Warranty for Mechanical Components.
- Limited Five (5) Year Warranty for Electrical Components.
Product Specifications:
- Type: Hydraulic
- Mount Type: Vehicle Mounted
- Recommended Use: Industrial
- Voltage: Not Applicable
- Motor Horsepower: Not Applicable
- Electrical Control Type: Not Applicable
- Thermal Shutoff: No
- Drive Gear Type: Planetary
- Gear Reduction Ratio: 28.5:1
- Free Spooling: Yes
- Brake Type: Spring Applied Disc
- Line Diameter (IN): No Rope
- Line Length (FT): No Rope
- Line Material: No Rope
- Fairlead Type: No Fairlead
- Conforms to J706 Standards: Yes
- Remote Type: No Remote
- Mounting Hole Quantity: 8
- Operation Type: Automatic
- Mounting Pattern Length (IN): 18 Inch
- Mounting Pattern Width (IN): 7-1/2 Inch
- Includes Mounting Hardware: No
- Color: Black
- Max Line Pull / Line Speed: 20,000 Pounds / 28.5 Feet Per Minute
- Application Type:
- Commercial
- Load Rating (lbs.):
- 20000.0
- Line Type:
- Not Included
- Title:
- SERIES WINCH
- Integrated Solenoid:
- N/A
