4,500 lbs. (2,041 kg) line pull. Power in and power out. High torque permanent magnet motor delivers high line pull at lower amp and slip free dynamic brake. 3-stage planetary gearbox delivers the most reliable and durable winch performance under the most rugged conditions. Sliding pin and ring gear clutch for rapid wire rope payout. Automatic load-holding mechanical brake and motor dynamic brake ensure holding the load without slippage. Standard Compliance: CE Machinery Directive 2006/42/EC CE Electromagnetic Compatibility Directive 2004/108/EC
- Rated Line Pull: 4,500 lbs. single line
- Motor: 1,200 w 1.6hp 12V permanent magnet
- Gear Ratio: 3-Stage Planetary 170:1
- Clutch (free-spooling): Sliding Ramping
- Brake (outside the drum): Automatic load holding mechanical brake
- Drum Size: 2.1" x 3.3"
- Control: Handheld pendant switch remote control
- Rope Type: Galvanized aircraft A7x19
- Rope Size: 1/4" x 50'
- Mounting Bolt Pattern: 3.4” x 3.7”
- Winch weight: 31.2 lbs.
- Gross weight: 40 lbs.
- Color:
- Black|Red
- Integrated Solenoid:
- N/A
